180m Hydraulic Crawler Mounted Borehole Rotary Blasting Water Well Drilling Machine
Machine Description
RCF180S is a compact, high-power, lightweight water well drilling rig with a maximum drilling depth of 180 meters,drilling diameter 90-300mm.
This water well drilling rig uses a very powerful diesel engine, a 77.3KW Yuchai engine, which ensures the powerful power of the drilling rig.
Maximum torque of the rotating head of this water well drilling rig is 4600N.m, and the lifting force is 15T. It is a small but powerful drilling rig.
This water well drilling rig uses a 2-meter-long drill rod, which is convenient for loading and unloading the drill rod.
This mini water drill is made of high-quality materials and has a stylish and compact design, which makes our drill more efficient, less prone to failure, more economical and durable, and has a high overall cost-effectiveness. Our water drill has been truly market-proven and has received positive feedback from most customers.
This small drilling rig has passed the CE certification and is more popular and well-received in Europe!
This drilling rig adopts the latest and advanced hydraulic technology, with low consumption, large rotary torque and easy operation. This water drilling rig is widely used in deep well drilling, farmland irrigation well drilling, geothermal well drilling, borehole drilling, small pile drilling and other projects.
Technical Parameters
| Bore diameter(hammer) | 90-300mm |
| Bore depth | 180m |
| Air consumption | 17-31m³/min |
| Air pressure | 1.7-2.5Mpa |
| Once-time advance length | 2.4m |
| Pipe diameter | 76mm/89mm |
| Pipe length | 2m |
| Push force | 4T |
| Lifting force | 15T |
| Max torque of rotary | 4000-4600Nm |
| Rotary speed | 45-65r/min |
| Mud Pump flow | 200L/min (option) |
| Feeding efficiency | 10-35m/h |
| Travel speed | 2.5Km/h |
| Climb ability | 30° |
| Dimension(L*W*H) | 2300×1200×1900mm |
| weight | 2700kg |
| Diesel engine | 77.3KW Yuchai engine |
Advantage
1. Small size, light weight, compact structure, flexible operation
The weight of the drilling rig is only 2700KGS, and the size of the whole machine is 2300X1200X2900mm
2. The drilling rig is a DTH pneumatic water drilling rig, with a dual motor rotating head and top drive. The drilling rig is equipped with a mud pump and an air compressor. The dual rotating motor increases the rotation torque and speed.
3. It has strong power and strong capacity. It adopts a 77.3KW Yuchai engine with a maximum drilling depth of 180m and a drilling depth of 90-300mm
4. Rubber crawler type, easy to move
5. Full hydraulic legs, convenient for truck transportation, and very stable drilling work
6. Full hydraulic operating system, optimized hydraulic system, supporting configuration, appearance, etc., to improve performance and work efficiency.
7. The mini water drilling rig is very suitable for water extraction in courtyards and narrow spaces
Image Display
